Notes
Disassembly And Assembly: Notes
Fig 1: Disassembling/Assembling A/C Compressor And Clutch Assembly With Torque Specification
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
