Removal And Installation: Notes
Pre-removal and post-installation operation
- Front deck garnish removal and installation, Refer to WINDSHIELD WIPER .
- Roof drip molding removal and installation, Refer to REMOVAL AND INSTALLATION .
- Front pillar trim removal and installation, Refer to TRIMS .
- Inside rear view mirror assembly removal and installation, Refer to INSIDE REAR VIEW MIRROR .
- Lighting control sensor removal and installation <Vehicles with lighting control sensor>, Refer to LIGHTING CONTROL SENSOR <VEHICLES WITH LIGHTING CONTROL SENSOR> .
- FCM/LDW/AHB-ECU Removal and Installation <Vehicles with FCM/LDW/AHB-ECU>, Refer to FCM/LDW/AHB-ECU .
