Removal And Installation: Notes
Pre-removal and post-installation operation
- Front Deck Garnish Removal and Installation (Refer to WINDSHIELD WIPER ).
- Roof Drip Molding Removal and Installation (Refer to REMOVAL AND INSTALLATION ).
- Front Pillar Trim Removal and Installation (Refer to INTERIOR TRIM ).
- Inside Rear View Mirror Assembly Removal and Installation (Refer to INSIDE REAR VIEW MIRROR ).
- Lighting Control Sensor Removal and Installation <Vehicles with Lighting Control Sensor> (Refer to LIGHTING CONTROL SENSOR ).
- FCM/LDW/AHB-ECU Removal and Installation <Vehicles with FCM> (Refer to FCM/LDW/AHB-ECU ).
