Removal And Installation: Notes
Pre-removal and post-installation operation
- Front deck garnish removal and installation (Refer to WINDSHIELD WIPER
.)
- Front pillar trim removal and installation (Refer to INTERIOR TRIM
.)
- Inside rear view mirror removal and installation (Refer to INSIDE REAR VIEW MIRROR
)
- Lighting control sensor removal and installation <Vehicles with lighting control sensor> (Refer to HEADLIGHT
.)
|
 Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
|
NOTE:
Do not apply double-sided tapes at the upper corner ends of part 2 [15 mm (0.59 in)].
 Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
|
