Removal And Installation: Notes
Pre-removal operation
Air Cleaner Intake Duct and Air Intake Hose Removal (Refer to
AIR CLEANER
).
Battery and Battery Tray Removal (Refer to
REMOVAL AND INSTALLATION
).
Engine Room Under Cover Front A, B Removal (Refer to
UNDER COVER
).
Post-installation operation
Engine Room Under Cover Front A, B Installation (Refer to
UNDER COVER
).
Battery and Battery Tray Installation (Refer to
REMOVAL AND INSTALLATION
).
Air Cleaner Intake Duct and Air Intake Hose Installation (Refer to
AIR CLEANER
).
Fig 1: Removing/Installing Starter Motor Assembly Components Location With Torque Specification
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
