| Pre-removal operation
|
Post-installation operation
- Drive Belt Installation (Refer to
- Crankshaft Pulley CRANKSHAFT PULLEY
) <2.0L ENGINE>.
- Drive Belt Installation (Refer to
- Crankshaft Pulley CRANKSHAFT PULLEY
) <2.4L ENGINE>.
- Drive Belt Tension Check (Refer to
- On-vehicle Service, Drive Belt Tension Check ON-VEHICLE SERVICE
) <2.0L ENGINE>.
- Drive Belt Tension Check (Refer to
- On-vehicle Service, Drive Belt Tension Check ON-VEHICLE SERVICE
) <20.4L ENGINE>.
|
