Home >> Nissan-Datsun >> 2012 >> Sentra SE-R >> Repair and Diagnosis >> Body & Frame >> Seats >> Service Information >> Front Seat >> Exploded View >> Passenger Seat

Passenger Seat

Fig 1: Exploded View Of Front Seat With Torque Specifications (Passenger)

G08503223

Courtesy of NISSAN NORTH AMERICA, INC.
