Ignition System: Overhaul: Reassembly

1. Inspect all bearing surfaces and pivot pins for roughness, binding, or looseness. Lubricate and install upper thrust washer on shaft and slide shaft into distributor housing.
2. Install distributor shaft retainer and pin. Install lower plate, upper plate, and pick-up coils as an assembly.
3. Position reluctor keeper pin into place on reluctor sleeve and firmly press reluctor into place. Make sure keeper pin is in place. Lubricate felt pad in top of reluctor sleeve and install rotor and cap.

Fig 1: Exploded View of V8 ESC Distributor
