Stationary Windows Component Views
| Callout | Component Name |
|---|---|
| 1 | Defogger Grid C2 |
| 2 | Center High Mounted Stop Lamp (CHMSL) |
| 3 | Tail/Turn and Stop Lamp-Right |
| 4 | Backup Lamp-Right |
| 5 | License Lamp |
| 6 | Backup Lamp-Left |
| 7 | Tail/Turn and Stop Lamp-Left |
| 8 | Defogger Grid C1 |
| Callout | Component Name |
|---|---|
| 1 | Cellular Microphone |
| 2 | Inside Rearview Mirror (UE1) |
| 3 | OnStar Button Assembly |
| 4 | Inside Rearview Mirror Lamps |
| 5 | Antenna |
| 6 | Cellular and Navigational Antenna |
| 7 | Remote Control Door Lock Receiver (RCDLR) |
| 8 | Vehicle Communication Interface Module (VCIM) |
