Rear Console Box: Disassembly

  1. REMOVE STEREO JACK ADAPTER ASSEMBLY
    1. Detach the 2 claws and remove the stereo jack adapter.
    2. Disconnect the connectors.
      Fig 1: Removing Stereo Jack Adapter
      G04159121Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
