Rear Console Box: Reassembly

  1. INSTALL STEREO JACK ADAPTER ASSEMBLY
    1. Connect the connectors.
    2. Attach the 2 claws to install the stereo jack adapter.
      Fig 1: Installing Stereo Jack Adapter
      G04159122Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
