Sliding Roof: Notes

Fig 1: Sliding Roof - Circuit Diagram (1 Of 2)
G07604555Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Sliding Roof - Circuit Diagram (2 Of 2)
G07604556Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
