Throttle Body: Components: Illustration

Fig 1: Identifying Throttle Body Replacement Components With Torque Specification (1 Of 2)
GTY160933Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002


Fig 1: Identifying Throttle Body Replacement Components With Torque Specification (2 Of 2)
GTY160937Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
