Power Source Control Ecu: Installation: Installation

HINT:

A bolt without a torque specification is shown in the standard bolt chart. Refer to SPECIFIED TORQUE FOR STANDARD BOLTS .

1. INSTALL POWER SOURCE CONTROL ECU
   1. Attach the 2 claws to install the power source control ECU.
      Fig 1: Installing Power Source Control ECU

      Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. INSTALL ECU INTEGRATION BOX RH
   1. Connect the 4 connectors.
   2. Install the ECU integration box RH with the nut and bolt.
3. INSTALL LOWER INSTRUMENT COVER RH  . Refer to INSTALLATION - Step 7
4. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY  . Refer to INSTALLATION - Step 8
