Engine Controls - Tests W/O Codes: Symptoms

Fig 1: Symptom Diagnosis - Impreza

Courtesy of SUBARU OF AMERICA, INC.

Fig 2: Symptom Diagnosis - Justy (1 of 3)

Courtesy of SUBARU OF AMERICA, INC.

Fig 3: Symptom Diagnosis - Justy (2 of 3)

Courtesy of SUBARU OF AMERICA, INC.

Fig 4: Symptom Diagnosis - Justy (3 of 3)

Courtesy of SUBARU OF AMERICA, INC.

Fig 5: Symptom Diagnosis - Loyale (1 of 2)

Courtesy of SUBARU OF AMERICA, INC.

Fig 6: Symptom Diagnosis - Loyale (2 of 2)

Courtesy of SUBARU OF AMERICA, INC.

Fig 7: Symptom Diagnosis - Legacy

Courtesy of SUBARU OF AMERICA, INC.

Fig 8: Symptom Diagnosis - SVX

Courtesy of SUBARU OF AMERICA, INC.
