Home >> Subaru >> 2014 >> Tribeca >> Repair and Diagnosis >> Body & Frame >> Windows >> Window Glass & Mirrors >> Remote Control Mirror Switch >> Removal

Remote Control Mirror Switch: Removal

  1. Remove the instrument panel lower cover. < Ref. to REMOVAL , Instrument Panel Lower Cover. >
  2. Disconnect the connector.
    Fig 1: Identifying Remote Control Mirror Switch Connector
    G08546536Courtesy of SUBARU OF AMERICA, INC.
  3. Remove the remote control mirror switch from instrument panel lower cover.
