Air Intake System

Fig 1: Exploded View Of Air Intake System With Torque Specification

G10263515

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T: 8 (0.8, 5.9)
