Crankshaft Position Sensor: Removal

Disconnect the ground cable from battery. Ref. to REPAIR CONTENTS>NOTE>BATTERY .
Remove the clip from the air intake boot, and loosen the clamp.

Fig 1: Locating Air Intake Boot Clip And Clamps
Courtesy of SUBARU OF AMERICA, INC.
Remove the air intake boot, and place it aside so that it does not interfere with the work.
CAUTION: Be careful not to pull out the PCV hose.

Fig 2: Removing Air Intake Boot
Courtesy of SUBARU OF AMERICA, INC.
Disconnect the connector (A) from the crankshaft position sensor, and remove the crankshaft position sensor from the cylinder block.

Fig 3: Locating Crankshaft Position Sensor Connector

Courtesy of SUBARU OF AMERICA, INC.
