Home >> Subaru >> 2021 >> Outback Base >> Repair and Diagnosis >> Restraints >> Air Bag, SRS >> Airbag System >> General Description >> Components With Torque Specifications >> Knee Airbag Module

Knee Airbag Module

Fig 1: Knee Airbag Module Nut

G13951723

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T: 7.5 (0.8, 5.5)
