Control Units
CONTROL UNITS LOCATION
| Component | Location |
|---|---|
| ABS Control Module | Left rear of engine compartment. See Figure . |
| Air-Bag Control Module (Sedan) | Below front console, forward of shift lever. See Figure . |
| Air-Bag Control Module (Wagon) | Below front console, forward of shift lever. See Figure . |
| Cruise Control Module | On engine, near throttle valve. See Figure . |
| Door Lock Controller (Sedan) | Behind lower left side of dash. See Figure . |
| Door Lock Controller (Wagon) | Behind lower left side of dash. See Figure . |
| DRL Controller | Behind dash, above left side of glove box. See Figure . |
| ECM | Behind glove box. See Figure . |
| 4 A/T Controller | Behind center of dash, below radio. See Figure . |
