Ignition Timing

IGNITION TIMING (Degrees BTDC @ RPM)

Application Base Timing Advance Timing
Camry 10 @ 700 13-27 @ Idle
Fig 1: Camry Firing Order & Distributor Rotation
G93245Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
