Neutral/Start Switch Specifications: Notes

NEUTRAL/START SWITCH SPECIFICATIONS VAN

Gearshift Position	Terminal Continuity
"P"	B & N
"R"	RB & RL
"N"	B & N

Fig 1: Neutral/Start Switch Terminal ID - Van

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
