Motor Relay Circuit Continuity

Disconnect 3 connectors from control relay. For location of relay, see Figure. Using a DVOM, there should be continuity between terminals No. 5 and 7. See Figure. Check that there is no continuity between terminals No. 1 and 3. If readings are not as specified, replace control relay.
