Circuit Protection Devices
CIRCUIT PROTECTION DEVICES
| Component | Component Location |
|---|---|
| Fuse Block No. 1 | On left side of engine compartment, clipped on side of R/B No. 2. |
| Fuse Block No. 2 | On J/B No. 1. |
| J/B No. 1 | Behind dash, left of steering column. See Figure. |
| R/B No. 2 | On left side of engine compartment. See Figure. |
| R/B No. 5 (Canada) | On left side of engine compartment. See Figure. |
| R/B No. 6 | Behind dash, left of steering column. See Figure. |
