Customize Parameters
- BUZZER ON/OFF SETTING
The buzzer ON/OFF setting, which is a setting of the buzzer function of the combination meter, can disable the driver's seat belt buzzer and front passenger's seat belt buzzer.
NOTE: Basically, these buzzers should be set on for safe driving. However, perform the following procedures only if it is necessary to set the buzzer off.PROCEDURE:
CUSTOMIZE PARAMETERSSteps Driver's Seat Belt Buzzer Front Passenger's Seat Belt Buzzer 1 Turn the ignition switch on (IG). Turn the ignition switch on (IG). 2 Press the ODO/TRIP switch until the odometer displays "ODO". Press the ODO/TRIP switch until the odometer displays "ODO". 3 Turn the ignition switch off. Turn the ignition switch off. 4 Turn the ignition switch on (IG) while depressing the brake pedal. Turn the ignition switch on (IG) while depressing the brake pedal. 5 Press the ODO/TRIP switch immediately (within 6 seconds) and hold it down for 10 seconds or more. Sit in the front passenger seat. Press the ODO/TRIP switch immediately (within 6 seconds after turning the power switch ON) and hold it down for 10 seconds or more. 6 Continue holding down the ODO/TRIP switch and fasten the driver's seat belt. Continue holding down the ODO/TRIP switch and fasten the front passenger's seat belt. 7 Check that the odometer displays either "b-on" or "b-off". ((1)) Check that the odometer displays either "b-on" or "b-off". ((1)) 8 Press the ODO/TRIP switch to change the display to "boff". Press the ODO/TRIP switch to change the display to "b-off". 9 Turn the ignition switch off. Turn ignition switch off. 10 Turn the ignition switch on (IG) while depressing the brake pedal. Turn the ignition switch on (IG) while depressing the brake pedal. 11 Check that no buzzer sounds. Check that no buzzer sounds when sitting on the front passenger's seat. (1) "b-off" indicates that the buzzer is OFF. "b-on" indicates that the buzzer is ON. The buzzer ON/OFF setting will be finished (the odometer will display "ODO") if the ODO/TRIP switch is not operated for 10 seconds or more. In this case, perform step 11 to check that buzzer ON/OFF setting is complete. If it is not complete, start from step 1 again. NOTE: When either the battery cable or the combination meter connector is disconnected, these buzzers are set on. - CUSTOMIZE PARAMETERS (Using a hand-held tester)
HINT:
The following items can the possible items to be customized.
NOTE:- Be sure to record the current value before customizing.
- When performing troubleshooting, be aware that the functions may be set to OFF by customizing. (Example: In case of the symptom in which "The wireless operation does not function", check that the wireless operation is not set to OFF by customizing, then perform the troubleshooting)
WARNING BUZZER:
CUSTOMIZE PARAMETERSDISPLAY (ITEM) DEFAULT CONTENTS SETTING KEY REMND VOLUM LARGE Function to change volume of key remind warning buzzer. Big / Middle / Small KEY REMND SOUND 900 ms Function to change cycle of key remind warning buzzer. 600 ms/ 900 ms/ 1,200 ms - TIME ZONE SETTING (w/Navigation system)
