Combination Meter: Reassembly

  1. INSTALL COMBINATION METER GLASS
    1. Install the combination meter glass with the 8 claws.
    2. Install the window plate with the 10 claws.
      Fig 1: Installing Window Plate
      G04466654Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    3. Install the trip knob.
      Fig 2: Installing Trip Knob
      G04466655Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
