Problem Symptoms Table
HINT:
- Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
- Inspect the fuses and relays related to this system before inspecting the suspected areas below.PROBLEM SYMPTOMS
Symptom Suspected Area See page Phenomenon of tight-corner braking* Linear solenoid circuit DTC C1298/98 LINEAR SOLENOID CIRCUIT 4WD control ECU - 4WD warning light remains on 4WD warning light circuit 4WD WARNING LIGHT REMAINS ON 4WD warning light does not come on 4WD warning light circuit 4WD WARNING LIGHT DOES NOT COME ON The system is in the DTC output mode although terminals TC and CG of the DLC3 TC and CG terminal circuit TC AND CG TERMINAL CIRCUIT 4WD warning light circuit - The system is not in the DTC output mode although terminals TC and CG of the DLC3 TC and CG terminal circuit TC AND CG TERMINAL CIRCUIT 4WD warning light circuit - HINT:
*: When driving 4WD mode, the vehicle is hard to turn, as if the brakes were applied, due to the rotational difference between the front and rear tires while turning.
