Ignition Timing
Warm engine to normal operating temperature. Check or adjust ignition timing with idle speed at specification and distributor vacuum hose disconnected and plugged. If necessary, loosen distributor hold-down clamp and rotate distributor.
IGNITION TIMING SPECIFICATIONS
| Application | RPM | Timing | |||
|---|---|---|---|---|---|
| 1974-76 Models | 800-850 2°ATDC | ||||
| 1977-79 Models | |||||
| Federal | 700-900 | (1) 10°BTDC | |||
| Calif. | 700-900 | 2°ATDC | |||
|
|||||
