Shift Mechanism: Removal

Remove shifter handle and console bezel.
If equipped with Autostick, disconnect the Autostick switch connector.
Loosen adjuster nut on shifter adjuster. See Fig 1.

Fig 1: Loosening Shift Cable Adjust Lever Nut
Courtesy of DAIMLERCHRYSLER CORP.
Disconnect shifter cable from shift pin and disconnect cable from shifter assembly bracket. See Fig 2.

Fig 2: Removing Floor Gearshift Cable
Courtesy of DAIMLERCHRYSLER CORP.
Disconnect interlock cable from shifter base slot. See Fig 3. Be careful not to break tab on interlock cable conduit end fitting.

Fig 3: Removing Interlock Cable
Courtesy of DAIMLERCHRYSLER CORP.
Remove the five floor pan attaching nuts from the shifter base and shift cable bracket. See Fig 4.

Fig 4: Removing Shifter Assembly
Courtesy of DAIMLERCHRYSLER CORP.
Remove shifter assembly from vehicle. See Fig 4.
