Door System - Front: Latch: Installation

NOTE: The screws attaching the door latch to the door end frame have nylon patches on the threads. All screws must be replaced when the latch has been removed.

Place door latch in position on door inner panel (Fig 1 ).
Position cables through access hole in water-shield.
Install screws attaching door latch to door end frame. Tighten screws to 10 N.m (90 in. lbs.) torque.
Insert linkages to door handle and engage clips.
Connect wire connector into power door lock motor and push pin into latch.
Connect key position switch connector. Install key position switch push pin fasteners (2) to the latch.
Verify door latch and power door lock operation.
Install watershield and front door trim panel. (Refer to INSTALLATION ) and (Refer to INSTALLATION ).
For proper latch adjustment procedures. (Refer to ADJUSTMENTS ).

Fig 1: Disconnecting Clips Holding Key Cylinder And Latch Rods To Outside Door Handle
Courtesy of DAIMLERCHRYSLER CORP.
