Disassembly And Assembly: Notes
For transfer case adapter disassembly procedures, follow numbered steps in illustration. See Fig 1. For transfer case adapter assembly procedures, follow numbers steps in illustration in reverse order. Letters in illustration refer to service point to observe while disassembling and assembling transfer case adapter. Letters with arrows pointing towards letter refer to service points to be observed while performing that step of the assembly procedure. See ASSEMBLY SERVICE POINTS .
Required Special Tools
- MB990929: Installer Adapter
- MB990938: Handle
