Component Testing: Injector

Disconnect 15-pin connector and check voltage between terminal E, A, B, J and ground. See Figure . There should be battery voltage. If okay, test is complete. If not, check each injector for continuity at connector. If there is continuity, check harness. If not, replace injector.
